Discontinued

SKU:H80B001XXW

G800 Aerial Helicopter Gimbal System Super Combo

G800 Aerial Helicopter Gimbal System Super Combo

Regular price $917.00 USD
Regular price $1,935.00 USD Sale price $917.00 USD
53% OFF Sold out
Shipping calculated at checkout.
View full details

Users must have a certain concept of security to operate the R/C helicopters.

Be sure to read and comply with related safety notes of instruction manual before flying.

Specification:

  • Characteristics : Soft Start
  • Rating Voltage:DC4.8~7.4V
  • Temperature Range:-20?~60?(-20°~140?)
  • Operating Range:540°(1000~2000us)
  • Broadband Systems: 1500μs
  • Stall Torque:15kg.cm(4.8V)
  • 18kg.cm(6V)
  • 20kg.cm(7.4V)
  • Motion Speed: 0.15sec/60°(4.8V)
  • 0.13sec/60°(6V)
  • 0.11sec/60°(7.4V)
  • Dimension: 40.1 x 20.1 x 20.7mm
  • Weight:66g

Specification(GS800 CONTROLLER):

  • Rating Voltage:DC4.8~8.4V
  • Temperature Range:-40°C~125°C (-40°~257°F )
  • Operating Current Consumption:
  • 55mA@ 6V(ROLL)
    40mA@ 6V(PAN)
  • Maximum Control range:

(ROLL) ±30°

(PAN) ±90°

(TILT) ±90°

  • Maximum Control rotation Speed:

(ROLL) 60°/ s

(PAN) 150°/ s

(TILT) 150°/ s

  • Dimension:42.7x 30 x 14.2mm
  • Weight:11g

Accessories:

  • G800 GIMBAL x 1 set
  • Gimbal Support Assembly x 1 set
  • Gimbal Shock Absorbers Assembly x 1 set
  • DS815 HV Robor Srevo x 3 set
  • GS800 Controller x 1 set
  • DS815 HV Robor Srevo x 3 set
  • ESC Mount x 1 pcs
  • G800 Gimbal Shock Absorbers Assembly x 1 set
  • G800 Gimbal Shock Accessory x 1 set
