Align T-rex 500X Top Combo Helicopter Kit (Belt Drive)

Align T-rex 500X Top Combo Helicopter Kit (Belt Drive)

Regular price $1,189.99 CAD
Regular price Sale price $1,189.99 CAD
0% OFF Sold out
Shipping calculated at checkout.
View full details

Experienced in numerous of innovations, the brand new T-REX 500XT is now ready to go. More attractive and creative design ideas are all in here, it absolutely would be your favorite T-REX 500XT model ever.


Refresh and refine, T-REX 500XT adapt with brand new FL rotor head system, utilizes an extremely low CG design which reduces resistance during 3D maneuvers while increasing flight responsiveness and precision. A progressive design adds a gloss silver and red anodizing appearance which continue our quality development based on our 700 class helicopter. The T-REX 500XT main frame utilizes composite material integration technology on carbon side frame plates, including the addition of battery mounting side rails, and a top motor mount design. Innovative adjustable belt guide pulley, allows a convenient way to adjust the belt tension by releasing or tightening the screw. The screw is used to maintain optimal belt tension over time to keep the best. Also T-REX 500XT landing skid is tilted 5 degrees forward to improve crashworthiness.

T-REX 500XT utilizes 470mm main blades and 520MX(1600KV/3527) motor with 20% power upgrades than the original 1600KV/3225 motor. The latest new RCE-BL80X Brushless ESC support dual BEC output from 6 ~ 8.4V providing efficient and superior power. The NEW DS530M/DS535M digital servos are with extreme torque and speed response allow to support faster, more precise and accurate flight performance.

Equipped with all the top end electronic devices, T-REX 500XT is as stable and powerful like the large scale helicopters. It is about to re-define the 500-class helicopters in your mind.

Focus Shots

Standard equipment

  • RCE-BL80A Brushless ESC x 1
  • 520MX Brushless Motor(1600KV/3527) x 1
  • DS530M Digital servo x 3
  • DS535M Digital servo x 1
  • Microbeast PLUS Flybarless System x 1 set

Specification

  • Length: 935mm
  • Height: 259mm
  • Width: 151mm
  • Main Blade Length: 470mm
  • Main Rotor Diameter: 1054mm
  • Tail Rotor Diameter: 219mm
  • Motor Pinion Gear: 12T
  • Main Drive Gear: 134T
  • Main Drive Pulley: 80T
  • Tail Drive Gear: 21T
  • Drive Gear Ratio: 11.17:1:3.81
  • Weight(w/o battery): approx. 1450g

Accessories

  • T-REX 500X KIT Set x 1
  • Microbeast PLUS Flybarless System x 1 set
  • 470 Carbon Fiber Blades x 1
  • 78 Tail Rotor Blade x 1
  • 520MX Brushless Motor(1600KV/3527) x 1
  • DS530M Digital servo x 3
  • DS535M Digital servo x 1
  • RCE-BL80A Brushless ESC x 1

Radio transmitter and electronic equipment required for assembly

  • Transmitter(6-channel or more, helicopter system)
  • Receiver(6-channel or more)
  • 6S Li-Po 2600 ~ 3300mAh (3300mAh suggestion)
  • Digital Pitch Gauge
