Xnova Motors

XN-3215-945

Xnova TAREQ EDITION 3215-945KV V2 (Shaft A) - Goblin 380/ Buddy/ Raw 420 Competition

Xnova TAREQ EDITION 3215-945KV V2 (Shaft A) - Goblin 380/ Buddy/ Raw 420 Competition

$212.99 CAD
$212.99 CAD
0% OFF Sold out
Shipping calculated at checkout.
View full details

Tareq Edition motors are the most powerful motors that made for the well-known world-class 3D pilot - Tareq Alsaadi to provide the power he needs for his extreme 3D style flying. All Xnova motors are 100% hand-wound and pre-tested carefully at the factory before shipping.

The Xnova brushless high-performance outrunner motor is engineered for extreme 3D flight, delivering unparalleled power in helicopters with blade sizes ranging from 360mm to 420mm. Designed for maximum power-to-weight efficiency, this motor offers exceptional performance while maintaining outstanding energy efficiency.

  • Enhanced efficiency through thinner stator laminations and an integrated cooling system, resulting in lower operating temperatures.
  • Increased power output with thicker, hand-wound YY single-strand copper wires, heat-resistant up to 250°C.
  • High-performance neodymium magnets, heat-resistant up to 150°C, contributing to superior overall performance.
  • 100% hand-wound construction for exceptional quality and precision.
Specifications:
  • Slots & Poles: 12n10p
  • Winding T: YY
  • rpm/V: 945
  • Volt (V): 10 / 22.2
  • Io(A): 1.4 / 2.4
  • Rm (mohm): 24 / 24
  • Weight (without connector): 166g
  • Body Length (no shaft): 40mm
  • Diameter: 40.5mm
  • Shaft Length: 22mm
  • Shaft Dia.: 5mm
  • Mounting Holes CTC Distance: 25mm
  • Mounting Screw: M3x0.5
  • Max Eff. Curr.: 24.15 / 47.12
  • Max Eff.: 88.41 / 89.81
  • Kt (Nm/A): 0.0101
  • Km (Nm/sqrt(w)): 0.0652
  • Max Continuous Power: 1350W
  • Peak Continuous Power (For 2 secs): 1800W
  • Max Continuous Current: 60A
