Align DS535M Digital Servo

Align DS535M Digital Servo

$119.99 CAD
$119.99 CAD
0% OFF Agotado
Los gastos de envío se calculan en la pantalla de pago.
Ver todos los detalles
Instruction:
  • Coreless Motor Design for fast speed, high efficiency, and low power consumption.
  • Higher signal resolution for smooth movements.
  • Response time of 0.035s/60°. High rigidity metal gears with high precision and durable structure characteristics.
  • Aluminum alloy mid case construction for instantaneous heat dissipation, maintaining servo’s high efficiency.
  • Supports high voltage 8.4V.
  • Powerful and precise servo suitable for T-Rex 500 CCPM cyclic and rudder servo use.
Specification:
  • Stall torque: 5.0kg.cm(6.0V) / 6.5kg.cm(8.4V)
  • Motion speed: 0.05sec/60°(6.0V) / 0.035sec/60°(8.4V)
  • Rating voltage: DC 6.0-8.4V
  • Temperature range: -20°C ~ +60°C
  • Dimension: 35.1 x 15.1 x 29mm
  • Weight: 36g
Accessories:
  • DS535M Digital Servo x 1
  • Servo Arm x 1
  • DS515/525 Servo Arm Set x 1
  • Socket Button Head Self Tapping Screw x 4(T2.6x12mm)

Customer Reviews

Based on 2 reviews
100%
(2)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
D
Darryl Carpenter
Align Trex Tail Servo

My heli was suddenly showing lack of tail authority and even with larger tail blades, no better. Nothing in Forward Programming seemed to help so I replaced the tail servo, did a few tweaks in the Tx and worked great.
On one hand that fixed it but not a great servo of it wore out in less than a year. On the other hand, maybe it was my error somewhere and the servo was really OK????

J
Jery Ralainony
Great customer services

Always a pleasure to purchase from. Quite fast for all the deliveries I have had. The packages are safely placed and wrapped. The servo seems to be very solid as all align parts….
